2-2
Support for a Variety of Scenes and
Measurement Lines
You can have more than one setting for a measurement flow, depending on the inspections. This is
called a scene and you can set up to 128 scenes. Refer to 5-1 What Is a Scene? on page 5 - 2.
You can also combine more than one scene into a scene group. Management of scenes by scene
groups increases the number of scenes that you can handle. Refer to 7-1 What Is a Scene Group? on
page 7 - 2.
Image Input
Defect
Search
Measurement flow
Output Unit
Scene groups (0 to 31)
Scene group 0
Scenes (0 to 127)
Scene 0
If you have more than one measurement line, the FH allows you to selectively execute up to eight
measurement lines. This allows you to maintain settings for the scenes and scene groups for every
line from 0 to 7. You can connect up to eight Cameras to the FH, and selectively control each Camera.
Refer to Multi-line Random-trigger Mode on page 4 - 18.
2 Features
2 - 4
FH/FHV Series Vision System User’s Manual (Z365-E1)
