6-5
Updating the Reference Position Data
for a Unit in the Measurement Flow
[Update Standard Position Tool]
This section describes the use of a table to set or change the reference position for more than one
processing unit that you specify in the measurement flow.
To open the Update Standard Position Tool, select Update standard position tool from the Tool
menu.
This function cannot be used with the FHV series.
Items That Can Be Updated with the Update Standard Position Tool
You can specify the following processing items.
• Search • EC Cross
• Search II • Edge Position
• Sensitive Search • Scan Edge Position
• Shape Search II • Circular Scan Edge Position
• Shape Search III • Intersection
• EC Circle Search • Gravity and Area
• ECM Search • Labeling
• EC Corner
Operating Procedure for the Update Standard Position Tool
You can update the reference position for measurement items in the flow without the need to open the
settings dialog box for each item.
For example, you can easily update the reference position that is updated frequently in an alignment
application.
To update the reference position, display the image to use as the reference in advance. When you
click the Measure ref. button, the Controller measures the reference for all units that are selected in
the Unit Setting list and updates the reference position.
If you click the reference position in the window, or enter the coordinates as a numeric value, the refer-
ence positions for the selected units in the Unit Setting list are updated with this value.
6 Performing Measurement and Adjustment
6 - 34
FH/FHV Series Vision System User’s Manual (Z365-E1)
