9-2
Saving Settings Data to the Flash
Memory
This section describes the procedure to save settings data (system data, scene data, and scene group
data) in the flash memory of the Sensor Controller. Make sure to save setting data when settings have
been changed.
Every time you restart the Sensor Controller, the data in the memory is loaded and enabled.
Precautions for Correct Use
• If Save to file is performed for System + scene group 0 data, the data being saved will also
be saved to the Controller’s flash memory at the same time. Do not turn OFF the power sup-
ply during this process. The Controller may not start up properly the next time it is turned ON.
• During data transfer to external storage, do not remove the external storage device until the
transfer is completed. Data and the external storage may be corrupted.
1
Click Save to file on the toolbar in the Main Window.
A confirmation message is displayed.
2 Click OK.
The system data and all Scene group data are saved in the flash memory in the Controller by
default.
If you connect more than one the external storage to the Controller, confirm in the File Explorer
window that the external storage you wish to save the Scene group data to is recognized as a
drive.
Refer to 9-1-2 External Drive Names on page 9 - 5.
Additional Information
If an external storage device is not inserted, a confirmation message is displayed.
If OK is clicked, only system data and data from scene group 0 are saved in the Controller’s
flash memory.
9 Saving/Loading Data
9 - 7
FH/FHV Series Vision System User’s Manual (Z365-E1)
9-2 Saving Settings Data to the Flash Memory
