Omron fh series User Manual

Item
Setting value
[Factory default]
Description
Font Setting - Sets display font.
Size 1 to 100 [9] Sets the font size.
Style
• Bold
• Italic
• Underline
• Strikeout
Sets the font style.
Check the box of your desired style.
Color Setting - Sets the font color, background color, and the background color at
selection.
Fore Color R: 0 to 255 [16]
G: 0 to 255 [16]
B: 0 to 255 [16]
Sets the character color.
Back Color Set the button color in normal state.
Select Col-
or
Set the button color in select state.
Initial Setting - Sets the startup default conditions for the data setting buttons.
Initial Sta-
tus
• [Active]
• Inactive
Sets the button operation enabled or disabled when starting up
the sensor controller.
Precautions for Correct Use
• Set subroutine name to specify in Set operation in accordance with the following rules.
* + Single-byte alphabetical character + Single-byte alphanumeric character and _
(underscore)
Example:*MEASUREDISP
• In Control setting, if using a macro RaiseOptionEvent to operate, then specify the control
command in the event number, and the control parameters in the parameter.
8-3-24
Simple Data Grid Window (MDI_SimpleDataGrid.dll)
A window part for displaying it on the main screen as a table.
A grid screen like below is displayed.
8 Setting Windows
8 - 58
FH/FHV Series Vision System User’s Manual (Z365-E1)
