9-10
Outputting a list of Scene Data Set-
ting Values [Setting Values Download/
Upload Tools]
In order to generating a list of setting values of scene data, use the Settings download and upload
tools.
With using the download function,setting values of the specified scene data can be downloaded as a
CSV file format. By opening the CSV file with a editor, differences in setting values of multi scene data
can be easily identified. (Only data with Set/Get attribute can be downloaded.)
With using the upload function, a CSV file whose setting values have already been identified can be
uploaded.
9-10-1
Downloading Setting Values
1 Switch to a scene containing the setting values to download.
2 When saving data to external storage, insert an external storage device into the Sensor Con-
troller.
3
In the adjustment window (layout 0), select Settings download and upload tools from the
Tool menu.
4
Click Download and select the scene with the set values to download.
5 Specify the save destination folder and file name, and click OK.
9 Saving/Loading Data
9 - 49
FH/FHV Series Vision System User’s Manual (Z365-E1)
9-10 Outputting a list of Scene Data Setting Values [Setting Values Download/Upload Tools]
9
9-10-1 Downloading Setting Values
To Next Page
