Machine Simulator processing item Set the machine setting processing item to reference, and
then set the conditions of the actual coordinates to confirm.
↓
Position measurement processing item
Measure the position of the alignment marks or the position
of a special feature of the workpiece from the image in Cam-
era 1.
Out of the general measurement processing items
(Inspections and Measurements), you can use processing
items with measurement results that have an X and Y in the
calculation strings.
To output the position on the image, set Calibration on the
Output parameter tab page to OFF.
↓
Vision Master Calibration processing item
Set the machine setting processing item to reference, and
then set the sampling.
• Using the Flow:
The motionless workpiece (or a saved image) is continuously measured until the calibration is
completed. This allows you to easily verify the operation of the calibration flow with the FH/FHV
series Controller. Conventionally, you could not verity the calibration flow unless the Controller
was integrated into the system.
Refer to Machine Simulator of the Vision System FH/FHV Series Processing Item Function
Reference Manual (Cat. No. Z341).
10-9-5
Alignment Processing Items
The following processing items can be used as alignment processing items.
Refer to the following manual for details on processing items. Refer to Vision System FH/FHV Series
Processing Item Function Reference Manual (Cat. No. Z341).
Processing item
category
Sub category
Processing item
name
Description
Measurement
support process-
ing items
(Inspection and
measurement
support items)
Machine setting
processing items
Stage Data This processing item sets and retains data that is
related to a stage.
Enter the data based on the specifications of the
stage to use.
Robot Data This processing item sets and retains data that is
related to the robot.
Enter the data based on the specifications of the
robot to use.
10 Advanced Usage
10 - 67
FH/FHV Series Vision System User’s Manual (Z365-E1)
10-9 Positioning workpieces for stage and
robot applications [Alignment Function]
10
10-9-5 Alignment Processing Items
