Parker EME
Introduction
192-120114 N5 C3I22T11 June 2008 19
1.6.2. Conditions of utilization for UL certification Compax3S
UL certifiction for Compax3S
conform to UL:
according to UL508C
Certified
E-File_No.: E235 342
The UL certification is documented by a ”UL” logo on the devi-
ce (type specification plate).
”UL” logo
Conditions of utilization
The devices are only to be installed in a degree of contamination 2 environment
(maximum).
The devices must be appropriately protected (e.g. by a switching cabinet).
The X2 terminals are not suitable for field wiring.
Tightening torque of the field wiring terminals ( green Phoenix plugs)
C3S0xxV2
0.57 - 0.79Nm 5 - 7Lb.in
C3S1xxV2,
C3S0xxV4, C3S150V4
0.57 - 0.79Nm 5 - 7Lb.in
C3S300V4
1.25 - 1.7Nm 11 - 15Lb.in
Temperature rating of field installed conductors shall be at least 60°C Use copper
lines only
Please use the cables described in the accessories chapter (see page 340, see
page 342), they do have a temperature rating of at least 60°C.
Maximum ambient temperature: 45°C.
Suitable for use on a circuit capable of delivering not more than 5000 rms sym-
metrical amperes and 480 volts maximum.
ATTENTION
Danger of electric shock.
Discharge time of the bus capacitator is 5 minutes.
The drive provides internal motor overload protection.
This must be set so that 200% of the motor nominal current are not exceeded.
Cable cross-sections
Mains input: corresponding to the recommended fuses.
Motor cable: (see page 359) corresponding to the nominal output currents
(see page 395, see page 394)
Maximum cross-section limited by the terminals mm
2
/ AWG
C3S0xxV2
2.5mm
2
AWG 12
C3S1xxV2,
C3S0xxV4, C3S150V4
4.0mm
2
AWG 10
C3S300V4
6.0mm
2
AWG 7
