Parker Compax3 Series User Manual

Parker EME
Compax3 Accessories
192-120114 N5 C3I22T11 June 2008 363
9.4 External braking resistors
In this chapter you can read about:
Permissible braking pulse powers of the braking resistors ..............................................364
Dimensions of the braking resistors
.................................................................................373
Danger!
Hazards when handling braking resistors!
Housing temperature up to 200°C!
Dangerous voltage!
The device may be operated only in the mounted state!
The external braking resistors must be installed such that contact with
the human body is prevented.
Install the connecting leads at the bottom.
Observe the instructions on the resistors (warning plate).
Please note that the length of the supply cable must not exceed 2m!
Ballast resistors for Compax3
Braking Resistor (see page 363) Device Rated Power
BRM08/01 (100Ω)
Compax3S025V2
Compax3S015V4
Compax3S038V4
60W
BRM05/01 (56Ω)
Compax3S063V2
Compax3S075V4
180W
BRM05/02 (56Ω)
Compax3S075V4 570W
BRM10/01 (47Ω)
Compax3S150V4 570W
BRM04/01 (15Ω)
Compax3S150V2
Compax3S300V4
Compax3MP20D6
570W
BRM04/02 (15Ω)
Compax3S150V2
Compax3S300V4
Compax3MP20D6
740W
BRM04/03 (15Ω)
Compax3S300V4
Compax3MP20D6
1500W
BRM09/01 (22Ω)
Compax3S100V2 570W
BRM11/01 (27Ω)
Compax3H0xxV4 3500W
BRM13/01 (30Ω)
Compax3MP10D6
Compax3MP20D6**
500 W
BRM14/01 (15Ω)
Compax3MP10D6*
Compax3MP20D6
500 W
BRM12/01 (18Ω)
Compax3H1xxV4 4500W
*for Compax3MP10D6 2x15Ω in series
**for Compax3MP20D6 2x30Ω parallel
