Parker EME
Compax3 Accessories
192-120114 N5 C3I22T11 June 2008 349
9.2 EMC measures
In this chapter you can read about:
Mains filter ........................................................................................................................349
Motor output filter..............................................................................................................353
Mains filter ........................................................................................................................354
9.2.1. Mains filter
For radio disturbance suppression and for complying with the emission limit values
for
CE conform operation (see page 16)we offer mains filters:
Observe the maximum permitted length of the connection between the mains filter
and the device:
unshielded <0.5m;
shielded < 5m (fully shielded on ground – e.g. ground of control cabinet)
Order code mains filter Compax3S
/
for C3S025V2 or S063V2
NFI
0 1 / 0 1
for C3S0xxV4, S150V4 or S1xxV2
NFI
0 1 / 0 2
for C3S300V4
NFI
0 1 / 0 3
Order code mains filter Compax3MP
/
for C3MP10 Reference axis combination 3x480V 25A
6x10m motor cable length
NFI
0 3 / 0 1
for C3MP10 Reference axis combination 3x480V 25A
6x50m motor cable length
NFI
0 3 / 0 2
for C3MP20 Reference axis combination 3x480V 50A
6x50m motor cable length
NFI
0 3 / 0 3
Order code mains filter Compax3H
/
for C3H050V4
NFI
0 2 / 0 1
for C3H090V4
NFI
0 2 / 0 2
for C3H1xxV4
NFI
0 2 / 0 3
