Communication
C3I22T11
288 192-120114 N5 C3I22T11 June 2008
In this chapter you can read about:
Compa3 communication variants .....................................................................................288
COM port protocol
............................................................................................................300
Remote diagnosis via Modem ..........................................................................................305
DeviceNet.........................................................................................................................309
Here you will find the description of the fieldbus interfaces, which can be configured
in the Compax3 ServoManager under the tree entry "configuring the communica-
tion".
The configuration of the process data (Mapping) is made wizard-guided with the
Compax3 ServoManager.
If you perform the mapping directly via the master, you must go through this fiel-
dbus wizard once; the Compax3 ServoManager will perform the necessary initiali-
zations.
5.1 Compa3 communication variants
In this chapter you can read about:
PC <-> Compax3 (RS232) ...............................................................................................289
PC <-> Compax3 (RS485
) ...............................................................................................290
PC <-> C3M device combination (USB)
...........................................................................291
USB-RS485 Moxa Upo
rt 1130 adapter ...........................................................................292
ETHERNET-RS485 NetCO
M 113 adapter.......................................................................293
Modem Westermo TD-3
6 485 ..........................................................................................295
C3 settings for RS485 two w
ire operation ........................................................................298
C3 settings for RS485 four w
ire operation .......................................................................299
Overview of all possible communication modes between Compax3 deviecs and a
PC.
5. Communication
