Parker EME
Compax3 device description
192-120114 N5 C3I22T11 June 2008 27
3.2 Meaning of the status LEDs - Compax3MP (mains
module)
C3MP Status LEDs Left LED (green) Right LED (red)
Control voltage 24 VDC iss missing** off off
Error of mains module* off on
DC power voltage is built up - Flashes quickly
Phase failure / mains power supply undervoltage on Flashes slowly
Address assignment CPU active Flashes quickly -
Address assignment CPU completed Flashes slowly -
C3MPxx Ready - State on off
Incorrect wiring of internal communication X30/31 Flashes slowly Flashes quickly
*can be read out in each axis controller
Caution!
When the control voltage is missing there is no indication whether or
not high voltage supply is available.
