Parker EME
Compax3 Accessories
192-120114 N5 C3I22T11 June 2008 377
9.6 Connection set for Compax3MP/Compax3M
The connection set which is available as accessory comprises:
for Compx3M
Cable clamps in different sizes for large area shielding of the motor cable, the
screw for the cable clamp as well as
the matching plug for the Compax3M connectors X14, X15, X43
a toroidal core ferrite for a cable of the motor holding brake
an interface cable (SSK28/23) for communication within the axis combination
for Compx3MP
the matching plug for the Compax3MP connectors X9, X40, X41
2 bus terminal connectors (BUS07/01) for mains module and the last axis control-
ler in the combination
Order Code connection set for Compax3MP/Compax3M
/
for C3M050D6, C3M100D6, C3M150D6 ZBH 04/01
ZBH
0 4 / 0 1
for C3M300D6 ZBH 04/02
ZBH
0 4 / 0 2
for C3MP10 ZBH 04/03
ZBH
0 4 / 0 3
C3MP20 ZBH 04/03
ZBH
0 4 / 0 4
ZBH04/01: for Compax3M050-150D6
ZBH04/02: for Compax3M300D6
ZBH04/03: for Compx3MP10D6
ZBH04/04: for Compax3MP20D6
