Parker EME
Communication
192-120114 N5 C3I22T11 June 2008 307
5.3.3. Configuration of remote modem 2
Settings in Compax3 under "configure communication: Modem settings":
Modem initialization = "ON": After the SSK31 modem cable has been connected,
Compax3 initializes the modem
Modem initialization after Power On = "ON": After Power on of Compax3, the
device initializes the modem
Modem check = "ON": a modem check is performed
The timeout periods are set to reasonable standard values according to our expe-
rience.
Select the modem type: "Westermo TD-33" or "user-defined modem"
For "Westermo TD-33", no further settings are required.
For "user-defined modem", additional settings are only required, if the modem
does not support standard AT commands.
Then you can enter special AT commands.
Note: When operating the local modem on a telephone system, it may be ne-
cessary to make a blind dialling. Here, the modem does not wait for the dialling
tone. For the Westermo TD33, the additional command sequence is ATX3.
in the following wizard window, a specific download of the modem configuration
can be made.
Note:
If a configuration download is interrupted, the original settings in the non volatile
memory of the Compax3 are still available.
You have to finish the communication on the PC side and to reset the Compax3 via
the 24V supply before you can start a new trial.
Reinitialization of the remote modem 2
Remove cable on Compax3 X10 and connect again!
