Parker EME
Setting up Compax3
192-120114 N5 C3I22T11 June 2008 245
4.3.7.3 Process of the automatic determination of the load
characteristic value (load identification)
Please click on "unknown: default values are used" in the configuration wizard in
the "External moment of inertia" window.
After the configuration download, you can enter directly, that the optimization
window is to be opened.
In the Commissioning window (left at the bottom) change to commissioning
mode.
Finally enter the values of the excitation signal and of the test movement in the
parameter window.
Parameters of the excitation signal:
Amplitude of the excitation signal in % of the motor reference current
Only an amplitude value causing a distinct disturbance can give a usable result.
Permissible following error
In order to avoid a following error caused by the excitation signal, the permissi-
ble following error must be increased for the measurement if necessary.
Selection of the test movement: inactive, reverse, continuous
Parameterizing of the test movement if necessary
Now energize drive in the commissioning window and open load identification
window.
Caution! Safeguard the travel range before energizing!
Starting the load identification.
Caution! The drive will perform a jerky movement during
load identification!
After the measurement, the values can be accepted. Depending on the applicati-
on, 2 measurements for minimum external load and maximum external load are
recommended.
