9.3 Connections to the motor
In this chapter you can read about:
Resolver cable..................................................................................................................356
SinCos© cable..................................................................................................................357
EnDat cable......................................................................................................................358
Overview of motor cables.................................................................................................358
Motor cable w
ith plug........................................................................................................359
Motor cable for t
erminal box.............................................................................................360
Encoder cable...................................................................................................................362
Under the designation "REK.." (resolver cables) and "MOK.." (motor cables) we
can deliver motor connecting cables in various lengths to order. If you wish to make
up your own cables, please consult the cable plans shown below:
Order code for motor cables
(2
/
for SMH / MH56 / MH70 / MH105
(3
(1.5mm
2
; up to
13.8A)
MOK
5 5 / ...
...
(1
for SMH / MH56 / MH70 / MH105
(3
(1.5mm
2
; up to
13.8A)
(cable chain compatible)
MOK
5 4 / ...
...
(1
for SMH / MH56 / MH70 / MH105
(3
(2.5mm
2
; up to
18.9A)
MOK
5 6 / ...
...
(1
for SMH / MH56 / MH70 / MH105
(3
(2.5mm
2
; up to
18.9A)
(cable chain compatible)
MOK
5 7 / ...
...
(1
for MH145 / MH205
(4
(1.5mm
2
; up to
13.8A)
MOK
6 0 / ...
...
(1
for MH145 / MH205
(4
(1.5mm
2
; up to
13.8A)
(cable chain compatible)
MOK
6 3 / ...
...
(1
for MH145 / MH205
(4
(2.5mm
2
; up to
18.9A)
MOK
5 9 / ...
...
(1
for MH145 / MH205
(4
(2.5mm
2
; up to
18.9A)
(cable chain compatible)
MOK
6 4 / ...
...
(1
for MH145 / MH205
(4
(6mm
2
; up to 32.3A) (cable chain compatible)
MOK
6 1 / ...
...
(1
for MH145 / MH205
(4
(10mm
2
; up to 47.3A) (cable chain compatible)
MOK
6 2 / ...
...
(1
(x
Note on the cable (see page 345)
Order code for feedback cables
/
for Resolver
(2
for MH / SMH motors
REK
4 2 / ...
...
(1
for Resolver
(2
for MH / SMH motors (cable chain compatible)
REK
4 1 / ...
...
(1
for SinCos© – Feedback devi-
ces
(2
for MH / SMH motors (cable chain compatible)
GBK
2 4
/
.. ...
(1
for EnDat 2.1
(2
for MH / SMH motors (cable chain compatible)
GBK
3 8 / .. ...
(1
Encoder – Compax3
GBK
2 3 / ...
...
(1
for LXR linear motors (cable chain compatible)
GBK
3 3 / ...
...
(1
for BLMA linear motors (cable chain compatible)
GBK
3 2 / ...
...
(1
(x
Note on the cable (see page 345)
