Parker Compax3 Series User Manual

Parker EME
Setting up Compax3
192-120114 N5 C3I22T11 June 2008 215
Symbol Description
p
K
Proportional term
signal is multiplied with K
p
T1
First order delay component (P-T1 component)
K
I
Integration block (I-block)
Kp,T
N
PI-block
Limitation block (signal limitation)
f
f
B
d
Notch filter (band elimination filter)
Addition block
blue descrip-
tion
Optimization objects
(simple pointer line)
red descripti-
on
Status objects
(pointer line with vertical stroke)
Optimization parameter Advanced
