Parker Compax3 Series User Manual

Communication
C3I22T11
308 192-120114 N5 C3I22T11 June 2008
5.3.4. Recommendations for preparing the modem operation
Preparations:
 Settings in Compax3 under "configure communication: Modem settings":
 Modem initialization: "ON"
 Modem initialization after Power On: "ON"
 Modem check: "ON"
 Deposit SSK31 cable in the control cabinet.
 Install modem in the control cabinet and connect to telephone line.
Remote diagnosis required:
 On site:
 Connect modem to Compax3 X10 via SSK31
 Modem is automatically initialized
 Local:
 connect modem to telephone line
 Establish cable connection to modem (COM interface)
 Select "connection via modem" under "options: communication settings
RS232/RS485...".
 Select modem under "selection"
 Enter telephone number
 Select COM interface (PC - modem)
 Establish connection with button (open/close COM port).
