Parker Compax3 Series User Manual

Parker EME
Compax3 Accessories
192-120114 N5 C3I22T11 June 2008 359
9.3.5. Motor cable with plug
MOK55/.. (max. 13.8A)
Cable: 6x1,5mm
2
PE ( )
0V
+24V
W
V
U
6
5
2
1
3
4
Br-
Br+
W
V
U
6
42
1
5
3( )
bk1
bk2
bk3
bk4
bk5
gn/ye
bk1
bk2
bk3
bk4
bk5
gn/ye
140 mm
75 mm65 mm
10 mm
Lötseite / solder side
Crimpseite / crimp side
Schirm auf Schirmanbindung selement
Screen at screen contact
Bremse/
Brake
1*
1*
 Strip cable on 140mm
 Cut off shield for about 65mm, loosen, fold back over external cover (for about
75mm) and fix with insulating tape.
 Fix 2x approx. 30mm shrinking hose (adhesive)
 Strip ends of lines for 10mm and fix terminal sleeves 1.5
MOK54/..: (max. 13.8A) cable chain compatible
Same structure (conductor coloring may be changed) as MOK55/.. available in
cable chain compatible version.
MOK56/..: (max. 18.9A)
Same structure (conductor coloring/designations may be changed) as
MOK55/.. but with 6x2.5mm
2
.
MOK57/..: (max. 18.9A) cable chain compatible
Same structure (conductor coloring / designation may be changed) as MOK55, but
with 4x2.5 + 2x1mm
2
and cable chain compatible.
You will find the length code in the
accessories order code (see page 342).
