Mains connection Compax3S0xxV2 1AC
Controller type S025V2 S063V2
Supply voltage
Single phase 230VAC/240VAC
80-253 VAC/50-60Hz
Input current
6Aeff 13Aeff
Maximum fuse rating per device
(=short circuit rating)
10 A (MCB miniature
circuit breaker)
16 A (MCB miniature
circuit breaker)
Mains connection Compax3S1xxV2 3AC
Controller type S100V2 S150V2
Supply voltage
Three phase 3* 230VAC/240VAC
80-253 VAC/50-60Hz
Input current
10Aeff 13Aeff
Maximum fuse rating per device
(=short circuit rating)
16 A (MCB miniature
circuit breaker)
20 A (MCB miniature
circuit breaker)
Mains connection Compax3SxxxV4 3AC
Controller type S015V4 S038V4 S075V4 S150V4 S300V4
Supply voltage
Three phase 3*400VAC/480VAC
80-528VAC / 50-60Hz
Input current
3Aeff 6Aeff 10Aeff 16Aeff 22Aeff
6A 10A 16A 20A 25A
Maximum fuse rating per
device(=short circuit
rating)
MCB miniature circuit breaker D*
* for UL conform operation (see page 19): MCB miniature circuit breaker S273-K.
Mains connection Compax3MP10D6
Device type Compax3MP10 230V 400V 480V
Supply voltage
230VAC ±10%
50-60Hz
400VAC ±10%
50-60Hz
480VAC ±10%
50-60Hz
Rated voltage
3AC 230V 3AC 400V 3AC 480V
Input current
22Aeff 22Aeff 18Arms
Output voltage
325VDC ±10% 565VDC ±10% 680VDC ±10%
Output power
6kW 10 kW 10 kW
Maximum fuse rating per
device (=short circuit rating)
MCB miniature circuit breaker according to DIVQ.GuideInfo
Recommendation: (ABB) S203 UP-25K (480VAC)
Mains connection Compax3MP20D6
Device type Compax3MP20 230V 400V 480V
Supply voltage
230VAC ±10%
50-60Hz
400VAC ±10%
50-60Hz
480VAC ±10%
50-60Hz
Rated voltage
3AC 230V 3AC 400V 3AC 480V
Input current
44Arms 44Arms 35Arms
Output voltage
325VDC ±10% 565VDC ±10% 680VDC ±10%
Output power
12kW 20kW 20kW
Maximum fuse rating per
device (=short circuit rating)
MCB miniature circuit breaker 50A according to
DIVQ.GuideInfo
Recommendation: (ABB) S203-U50K (440VAC)
Fuses 80A / 660VAC per supply leg according to UL-Guide
JFHR2
Recommendation: Bussmann 170M
