4.3.3.4 Setup and optimization of the control
In this chapter you can read about:
Standard .......................................................................................................................... 204
Advanced......................................................................................................................... 211
Commissioning window ................................................................................................... 226
Proceeding during controller optimization........................................................................ 228
For the setup and optimization of the control loops, the optimization window is avai-
lable.
The Compax3 control functionality is divided into 2 sections, standard and advan-
ced; the advanced functionality does however incorporate the entire standard fun-
ctionality. The switching can be made in the optimization window.
Switching between standard and advanced
Standard
In this chapter you can read about:
standard cascade structure ............................................................................................. 205
Standard optimization paramete
rs................................................................................... 206
Control signal limitations.................................................................................................. 206
Feedforward channels
..................................................................................................... 208
Control signal filter / filter of actual
acceleration value..................................................... 210
