Parker EME
Introduction
192-120114 N5 C3I22T11 June 2008 21
1.6.3. Conditions of utilization for UL certification Compax3M
UL certifiction for Compax3M
conform to UL:
according to UL508C
Certified
E-File_No.: E235 342
The UL certification is documented by a ”UL” logo
on the device (type specification plate).
Conditions of utilization
The devices are only to be installed in a degree of contamination 2 environment
(maximum).
The devices must be appropriately protected (e.g. by a switching cabinet).
Tightening torque of the field wiring terminals ( green Phoenix plugs)
Device X40: Braking Resistor X41: Mains connector X9: 24VDC
C3MP10
0.5 (4.43Lb.in) 1.2Nm (10.62Lb.in) 1.2Nm (10.62Lb.in)
C3MP20
0.5 (4.43Lb.in) 1.7Nm (15Lb.in) 1.2Nm (10.62Lb.in)
Device X43: Motor connector X15: Temperature monitoring
C3M050-150
0.5 (4.43Lb.in) 0.22Nm (1.95Lb.in)
C3M300
1.2Nm (10.62Lb.in) 0.22Nm (1.95Lb.in)
Temperature rating of field installed conductors shall be at least 60°C Use copper
lines only
Please use the cables described in the accessories chapter (see page 340, see
page 342), they do have a temperature rating of at least 60°C.
Maximum ambient temperature: 40°C.
Suitable for use on a circuit capable of delivering not more than 5000 rms sym-
metrical amperes and 480 volts maximum.
ATTENTION
Danger of electric shock.
Discharge time of the bus capacitator is approx. 5 minutes.
The drive provides internal motor overload protection.
This must be set so that 200% of the motor nominal current are not exceeded.
Cable cross-sections
Mains input: corresponding to the recommended fuses.
Motor cable: (see page 359) corresponding to the nominal output currents
(see page 395, see page 394)
Maximum cross-section limited by the terminals mm
2
/ AWG
Line cross-sections of the power connections (on the device bottoms)
Compax3 device: Cross-section: Minimum... Maximum[mm
2
with contactor slee-
ve]
M050, M100, M150
0,25 ... 4 (AWG: 23 ... 11)
M300
0,5 ... 6 (AWG: 20 ... 10)
MP10
Mains supply: 0,5 ... 6 (AWG: 20 ... 10)
Braking resistor: 0,25 ... 4 (AWG: 23 ... 11)
MP20
Mains supply: 0,5 ... 16 (AWG: 20 ... 6)
Braking resistor: 0,25 ... 4 (AWG: 23 ... 11)
