Setting up Compax3 C3I22T11
276 192-120114 N5 C3I22T11 June 2008
(5) Different settings and options
Functions available in a pull-down menu:
Open superposed control loops (see page 260)
accept load force
This serves, when opening the velocity controller, to accept the load which the
controller has provided at the time of switching off => a z-axis does not drop down
abruptly.
Measurement synchronous to the test movement
if this option is selected, it is ensured during the measurement, that the sampling
does not take place in the turning point during a movement.
Unless frequencies are generated due to the deceleration/acceleration of the drive,
which influence the measurement.
Result memory
In the result memory, the results of the N last measurements are kept.
This is important for the display of the cumulated measurement and for the casca-
de diagram. The larger the memory, the "older" the results still used. When the
contents is deleted, all old measurements are discarded and do no longer influence
the new results.
Windowing
(see page 256)
Here you can select different windowing modes for the measurement of frequency
spectra. As default, no window is used.
Save measure to file
The currently displayed measurement result is stored and can be uploaded later
into the ServoSignalAnalyzer. This does, however, not apply to the cascade dia-
gram display.
Open measure from file
Here you can reload the measurements memorized before. You have the possibili-
ty to load up to four measurements subsequently and display them together in a
graphic display.
Copy measurement to clipboard as graphic display.
The currently displayed measurement result is copied as pixel graphic (e.g. BMP)
to the clipboard.
