Specifications
192-120114 N5 C3I22T11 June 2008 403
Size / weight of Compax3S
Controller type Dimensions
HxWxD [mm]
Weight [kg]
Compax3S025V2
191 x 84 x 172 2.0
Compax3S063V2
191 x 100 x 172 2.5
Compax3S015V4
248 x 84 x 172 3.1
Compax3S100V2
248 x 115 x 172 4.3
Compax3S150V2
248 x 158 x 172 6.8
Compax3S038V4
248 x 100 x 172 3.5
Compax3S075V4
248 x 115 x 172 4.3
Compax3S150V4
248 x 158 x 172 6.8
Compax3S300V4
380 x 175 x 172 10.9
Minimum mounting distance: 15mm at the sides, above & below 100mm
Protection type IP20
Drawings, Mounting (see page 69)
Size / weight of Compax3MP/Compax3M
Device type Dimensions
HxWxD [mm]
Weight [kg]
Compax3MP10D6
360 x 50 x 263 3,95
Compax3MP20D6
360 x 100 x 263
Compax3M050D6
360 x 50 x 263 3,5
Compax3M100D6
360 x 50 x 263 3,6
Compax3M150D6
360 x 50 x 263 3,6
Compax3M300D6
360 x 100 x 263
Protection type IP20
Size / weight of Compax3H
Controller type Dimensions
HxWxD [mm]
Weight [kg]
Compax3H050V4
453 x 252 x 245 17,4
Compax3H090V4
668.6 x 257 x 312 32,5
Compax3H125V4
720 x 257 x 355 41
Compax3H155V4
720 x 257 x 355 41
Protection class IP20 when mounted in a control cabinet (not for Compax3H1xxxV4)
Drawings, Mounting (see page 69)
Safety technology Compax3S
Safe torque-off as per EN954-1, category
3
Certified: (BG-PRÜFZERT certification
number: 0403005)
 For implementation of the ”protection
against unexpected start-up” function
described in EN1037.
 Note the circuit examples circuit exam-
ples
(see page 78).
