1126700 SmartPAC 2 User Manual
4-6 Initialization Mode
Counter Setup Mode
(INITIALIZATION – POSITION SENSOR)
This item allows you to enable or disable counter setup mode if you have made the
appropriate wiring connections to make SmartPAC 2 “setup mode ready” (see Wiring Setup
Mode Circuit, page 2-31.) To set this parameter, do the following:
1. Press ENTER to toggle between two settings:
• “IS INCREMENTED IN ALL MODES”–Parts and batch counters will increment on
every stroke no matter what mode (i.e., Inch, Single-stroke, or Continuous) you are in.
• “NOT INCREMENTED IN SETUP MODE”–The Parts counter and batch counters
whose increment mode is programmed as GOOD PARTS will not increment when you
are in Inch mode.
2. When the setting you want is displayed, press RESET.
Counter Increment Mode
(INITIALIZATION – POSITION SENSOR)
This item, which is provided for SFC (see Appendix F) or LETS (see Appendix G) customers,
allows you to specify whether the Good Parts counter increments during a fault condition.
The default setting, NO INC FAULT, prevents the counter from incrementing when there is a
fault. To set this parameter, do the following:
1. Press ENTER to toggle between two settings:
• “NO INC FAULT”–The Parts counter and batch counters whose increment mode is
programmed as GOOD PARTS will increment on every stroke except when there is a
fault condition. This is the default setting.
• “INC ALWAYS”–The Parts counter and batch counters whose increment mode is
programmed as GOOD PARTS will increment on every stroke even if a fault condition
is present.
2. When the setting you want is displayed, press RESET.
The Strokes counter will increment regardless of the mode you are in.
