1126700 SmartPAC 2 User Manual
G-14 Reporting Downtime and Scrap to LETS
3. Press the Right () cursor key to move the cursor to the column for the SPEC. 1 sequence
number.
4. Press ENTER, and when the Numeric Entry window displays, type the numeric position
in which you want that downtime reason to appear on the Dialog Menu; then, press
ENTER to save your entry and return to the Dialog Special Choice Name Menu.
5. Move the cursor to the SPEC. 2 field, using the Down () cursor key, and repeat steps 2
through 4. Do the same for the remaining menu items.
6. When you have finished programming “special” downtime reasons, press RESET to save
your entries and return to the Set Communications Menu.
Documenting Downtime on the Dialog Menu
A downtime reason can be selected on the Dialog Menu either in response to the Forced
Dialog message or when the operator wants to change a previous downtime entry or add detail
to reported downtime.
Documenting Downtime in Response to the Forced Dialog Message
With Forced Idle Dialog mode or Forced Error Dialog mode enabled (see Making Downtime
Reporting Settings, page G-7), the operator is prompted to enter a downtime reason on the
Dialog Menu whenever SmartPAC 2 detects that the press has stopped under the appropriate
circumstances. This message is shown in Figure G-8, page G-15.
Remember to leave intervals between sequence numbers to allow room for “canned”
downtime reasons. See Selecting Canned Names on the Dialog Fixed Name Choice
Menu, page G-11.
If the same sequence number is assigned to both a “canned” and a “special” name, both
entries will display in that position on the Dialog Menu with the “special” name shown first.
