SmartPAC 2 User Manual 1126700
Run Mode 6-29
To change tool information, do the following:
1. Select TOOL INFORMATION on the Main Run Menu. The Tool Number Information
screen displays.
2. Select a parameter you want to change. The Numeric Entry window (see Figure 5-3,
page 5-3) displays.
3. Key in a new value, following the directions in the Numeric Entry window. For Yes/No
items, key in “0” for No, “1” for Yes. Press ENTER when you are finished. You are
returned to the Tool Number Information screen with your change displayed in the field
you selected in step 2.
4. Repeat steps 2 and 3 to change other parameters, as necessary.
5. To edit text in the memo box, press F4 for the first line, F5 for the second line. When the
Alphabetic Entry window (Figure 5-10, page 5-9) displays, key in your edits, following
the directions in the window, and press F6. The window closes, and your changes appear
on the memo box line you selected.
6. When you have finished changing tool information, press RESET to return to the Main
Run Menu.
Figure 6-23. Tool Number Information Screen
ARE YOU LOCKED OUT?
Access to items on this screen may be limited to Program mode or may require a
password. The security access settings in Initialization mode determine when changes
can be made. See Table 4-5, page 4-25.
