SmartPAC 2 User Manual 1126700
Installation 2-43
Test Complete
8. If you get to this step, SmartPAC 2 is working correctly. Clear any error messages by
pressing RESET, then delete the test tool. You can now create a tool in SmartPAC 2,
program settings for it, load it, and begin to make parts using your new SmartPAC 2.
What Next?
To program and use your SmartPAC 2, follow the instructions in the remaining chapters of
this manual. Go to Chapter 4 to make Initialization settings for your SmartPAC 2.
Table 2-10. SFI Port (1) and Module
Port (2) (TB103) Wiring
Pin # Signal Port
235 +RXD1 SFI PORT (1)
236 –RXD1 “
237 TXD1 “
238 +TXD1 “
239 –TXD1 “
240 GND “
241 +RXD2 MODULE
PORT (2)
242 –RXD2 “
243 +TXD2 “
244 –TXD2 “
Table 2-11. Special Port (3) and PACNet
Port (4) (TB104) Wiring
Pin # Signal Port
224 +RXD3 SPECIAL
PORT (3)
225 –RXD3 “
226 TXD3 “
227 +TXD3 “
228 –TXD3 “
229 GND “
230 +RXD4 PACNET
PORT (4)
231 –RXD4 “
232 TXD4 “
233 +TXD4 “
234 –TXD4 “
Wiring Tables for SmartPAC 2 Options
