D-8 SmartPAC to SmartPAC 2 Upgrade
Table D-7. SmartPAC 1 to SmartPAC 2 Wiring Changes: DiProPAC, 16-Channel
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
SENSOR 1 TB551 282
→
TB554 282
SENSOR 2 TB551 283
→
TB554 283
SENSOR 3 TB551 284
→
TB554 284
SENSOR 4 TB551 285 TB554 285
SENSOR 5 TB551 286 TB554 286
SENSOR 6 TB551 287 TB554 287
SENSOR 7 TB551 288 TB554 288
SENSOR 8 TB551 289 TB554 289
SENS. PWR. TB551 290 TB554 290
GND TB551 291 TB554 291
SENSOR 9 TB552 292 TB554 292
SENSOR 10 TB552 293 TB554 293
SENSOR 11 TB552 294 TB554 294
SENSOR 12 TB552 295 TB554 295
SENSOR 13 TB552 296 TB554 296
SENSOR 14 TB552 297 TB554 297
SENSOR 15 TB552 298 TB554 298
SENSOR 16 TB552 299 TB554 299
SENS. PWR. TB552 300 TB554 300
GND TB552 301 TB554 301
Table D-8. SmartPAC 1 to SmartPAC 2 Wiring Changes: ProCamPAC, 8-Channel
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
CHANNEL 1 TB401 260
→
TB401 260
CHANNEL 2 TB401 261
→
TB401 261
CHANNEL 3 TB401 262
→
TB401 262
CHANNEL 4 TB401 263 TB401 263
CHANNEL 5 TB401 264 TB401 264
CHANNEL 6 TB401 265 TB401 265
CHANNEL 7 TB401 266 TB401 266
CHANNEL 8 TB401 267 TB401 267
+ 5 VDC TB401 268 TB401 268
GND TB401 269 TB401 269
RELAY PWR. TB401 270 TB401 270
