2-22 Installation
2. Making sure that you are grounded, install the new board by plugging it into the
appropriate connector, J111 or J112 (see Figure 2-7, page 2-13). Connectors are keyed, so
you can only plug in the boards in one direction.
3. When the board is properly seated, screw it down to the four standoffs, using the screws
that came with the kit.
4. Remove the connector(s) from the board, one connector for an 8-sensor or 8-cam unit, two
connectors for a 16-sensor or 16-cam unit, four connectors for a 32-sensor unit. Terminal
block assignments for the different boards are as follows (see Figure 2-12 and
Figure 2-13, page 2-20):
• DiProPAC 8: Sensors 1-8 to TB554 upper
• DiProPAC 16: Sensors 1-8 to TB554 upper, sensors 9-16 to TB554 lower
• DiProPAC 32: Sensors 1-8 to TB554 upper, sensors 9-16 to TB554 lower, sensors 17-24
to TB555 upper, and sensors 25-32 to TB555 lower
• ProCamPAC 8: Cam channels 1-8 to TB401
• ProCamPAC 16: Cam channels 1-8 to TB451, channels 9-16 to TB452
5. Wire the connector(s) to the appropriate component(s). For the DiProPAC board, wire the
connector(s) to the DiPro Sensor Interface, following the instructions in Connecting DiPro
Sensor Interface to SmartPAC 2, page 2-22. For the ProCamPAC board, wire the
connector(s) to the ProCam Output assembly, following the procedure in Connecting
Programmable Cam Channels, page 2-25.
6. Plug the connector(s) back into their sockets on the board.
7. Verify that you have installed the board(s) properly by performing the Verifying
Installation of DiProPAC and ProCamPAC procedure, page 2-34. You need to complete
this procedure before you can use SmartPAC 2.
Connecting DiPro Sensor Interface to SmartPAC 2
To connect your DiPro die protection sensors through the DiPro Sensor Interface (DSI) 2,
refer to Table 2-3 (next page) to wire sensors 1-8, Table 2-4 to wire sensors 9-16, Table 2-5 to
wire sensors 17-24, and Table 2-6 to wire sensors 25-32. Wiring diagrams (Figure 1 for
sensors 1-16, Figure 2 for sensors 17-32) are provided at the back of the manual. Terminate
cable shields to ground studs close to the point of entry into the enclosure. Refer to the DSI 2
manual for more information.
DSI 2 NOT COMPATIBLE WITH LOW-IMPEDANCE SENSORS
If any of your sensors are low-impedance types, they must be wired directly to DiProPAC. Low-
impedance sensors cannot be wired to DSI 2.
