Wintriss SmartPAC2 User Manual

1126700 SmartPAC 2 User Manual
2-24 Installation
Table 2-5. DiPro Sensor Interface (DSI) 2 to SmartPAC 2 Wiring, Sensors 17-24
Wire color* 3rd DSI 2 (TB2) DiProPAC (TB555)
Pin # Pin Designation Pin # Pin Designation
Brown 1 SENSOR 1 180 SENSOR 17
Red 2 SENSOR 2 181 SENSOR 18
Orange 3 SENSOR 3 182 SENSOR 19
Yellow 4 SENSOR 4 183 SENSOR 20
Green 5 SENSOR 5 184 SENSOR 21
Blue 6 SENSOR 6 185 SENSOR 22
Violet 7 SENSOR 7 186 SENSOR 23
Gray 8 SENSOR 8 187 SENSOR 24
No connection 188 Sensor power
Black 9 GND 189 GND
10 GND No connection
11 +5 VDC No connection
Shield Terminate drain wire to ground
stud
Terminate drain wire to ground
stud
* Your colors may be different
Table 2-6. DiPro Sensor Interface (DSI) 2 to SmartPAC 2 Wiring, Sensors 25-32
Wire color* 4th DSI 2 (TB2) DiProPAC (TB555)
Pin # Pin Designation Pin # Pin Designation
Brown 1 SENSOR 1 190 SENSOR 25
Red 2 SENSOR 2 191 SENSOR 26
Orange 3 SENSOR 3 192 SENSOR 27
Yellow 4 SENSOR 4 193 SENSOR 28
Green 5 SENSOR 5 194 SENSOR 29
Blue 6 SENSOR 6 195 SENSOR 30
Violet 7 SENSOR 7 196 SENSOR 31
Gray 8 SENSOR 8 197 SENSOR 32
No connection 198 Sensor power
Black 9 GND 199 GND
10 GND No connection
11 +5 VDC No connection
Shield Terminate drain wire to ground
stud
Terminate drain wire to ground
stud
* Your colors may be different.
If there are extra wires in the cable, cut them off close to the end of the cable jacket.
