SmartPAC 2 User Manual 1126700
Installation 2-23
Table 2-3. DiPro Sensor Interface (DSI) 2 to SmartPAC 2 Wiring, Sensors 1-8
Wire color* 1st DSI 2 (TB2) DiProPAC (TB554)
Pin # Pin Designation Pin # Pin Designation
Brown 1 SENSOR 1 282 SENSOR 1
Red 2 SENSOR 2 283 SENSOR 2
Orange 3 SENSOR 3 284 SENSOR 3
Yellow 4 SENSOR 4 285 SENSOR 4
Green 5 SENSOR 5 286 SENSOR 5
Blue 6 SENSOR 6 287 SENSOR 6
Violet 7 SENSOR 7 288 SENSOR 7
Gray 8 SENSOR 8 289 SENSOR 8
No connection 290 Sensor power
Black 9 GND 291 GND
10 GND No connection
11 +5 VDC No connection
Shield Terminate drain wire to ground
stud
Terminate drain wire to ground
stud
* Your colors may be different
Table 2-4. DiPro Sensor Interface (DSI) 2 to SmartPAC 2 Wiring, Sensors 9-16
Wire color* 2nd DSI 2 (TB2) DiProPAC (TB554)
Pin # Pin Designation Pin # Pin Designation
Brown 1 SENSOR 1 292 SENSOR 9
Red 2 SENSOR 2 293 SENSOR 10
Orange 3 SENSOR 3 294 SENSOR 11
Yellow 4 SENSOR 4 295 SENSOR 12
Green 5 SENSOR 5 296 SENSOR 13
Blue 6 SENSOR 6 297 SENSOR 14
Violet 7 SENSOR 7 298 SENSOR 15
Gray 8 SENSOR 8 299 SENSOR 16
No connection 300 Sensor power
Black 9 GND 301 GND
10 GND No connection
11 +5 VDC No connection
Shield Terminate drain wire to ground
stud
Terminate drain wire to ground
stud
* Your colors may be different.
