SmartPAC 2 User Manual 1126700
Run Mode 6-7
In order to protect the tool, sensors should always be enabled except during setup and
troubleshooting when they can be temporarily disabled. You can wire (see page 2-31) and
enable (see page 4-20) a setup mode circuit that allows you to run the press in Inch during
setup with green sensors disabled. When Setup Mode is active, the message SENSORS IN
SETUP MODE is displayed in the Status Box in place of the SENSORS ENABLED message.
COUNTERS
(RUN – COUNTERS)
This item allows you to make adjustments to counter settings made in Program mode.
Adjustments are entered on the Counters screen (see Figure 6-9), which displays when you
select the COUNTERS item on the Main Run Menu.
If you temporarily disable sensors, be sure to re-enable them before you resume making parts.
For help with the Counters screen and screens accessible from it, press the HELP key when the
applicable screen is displayed.
ARE YOU LOCKED OUT?
Access to items on the Counters screen may be limited to Program mode or may require a
password. The security access settings in Initialization mode determine when changes can be
made. See Table 4-5, page 4-25.
Figure 6-9. Counters Screen
