1126700 SmartPAC 2 User Manual
6-16 Run Mode
CAM SWITCH (Optional)
(RUN – CAM SWITCH)
This item, which appears on the Main Run Menu only when ProCamPAC is installed, enables
you to adjust timing for each programmed cam channel. Adjustments are made via the Cam
Switch Menu (see Figure 6-18, page 6-17), which displays when you select CAM SWITCH.
The Cam Switch Menu displays a list of the cam channels that have been set up in Program
mode. If you have assigned names to your cam channels in Initialization mode, those names
will be displayed. Channels programmed as Global cams are not shown (see SET GLOBAL
CAMS (Optional), page 4-15).
Figure 6-17. Green Special Sensor Stroke Count Screen, Run Mode
PROGRAMMABLE CAM SWITCH NOT FOR SAFETY USE
Use SmartPAC 2’s programmable cam switch to control auxiliary functions only. The SmartPAC 2
programmable cam capability should never be used to provide timing signals for any safety use
including clutch/brake control or muting of light curtains.
Failure to comply with these instructions will result in death or serious injury.
For help with the Cam Switch Menu and the screens accessible from it, press the HELP key when
the applicable screen is displayed.
