SmartPAC 2 User Manual 1126700
Initialization Mode 4-23
9. Highlight the zero (0) on the first line in the PLACES column, and press ENTER. When
the Numeric Entry window displays (see Figure 4-7, page 4-10), key in a value, using the
numeric keypad or the Up () and Down () cursor keys, then press ENTER.
For numeric values, you can select up to four decimal places. For YES/NO items, enter
eight (8) for the number of places. Table 4-4 provides additional information about
decimal place formats.
Table 4-3. Tool Information Setup Screen: Abbreviations for Units
On-screen
Abbreviation Units
On-screen
Abbreviation Units
IN Inches METERS Meters
FT Feet FT/MIN Feet per minute
MM Millimeters FT/SEC Feet per second
CM Centimeters MM/SEC Millimeters per second
PSI Pounds per square inch MM/MIN Millimeters per minute
BAR Bars GALS Gallons
LBS Pounds QTS Quarts
TONS Tons GRAMS Grams
OUNCES Ounces SPM Strokes per minute
DEG. F Degrees Fahrenheit FPM Feet per minute
DEG. C Degrees Celsius MPM Meters per minute
Table 4-4. Tool Information Setup Screen: Decimal Places and Formats
No. of
Places Example
Digits to Left of
Decimal Point
Digits to Right of
Decimal Point Range
0 Whole numbers: press speed
(SPM)
Up to seven (7) None (0) 0 to
9,999,999
1 Up to five (5) One (1) 0.0 to
99,999.9
2 Die location (mm) Up to four (4) Two (2) 0.00 to
9,999.99
3 Pass line height (inches) Up to three (3) Three (3) 0.000 to
999.999
4 Precise values: material
thickness
Up to two (2) Four (4) 0.0000 to
99.9999
8 Yes or No designation Not applicable Not applicable NO (0)
YES (1)
Do not change the number of decimal places on the Tool Information Setup screen after
you have entered values for specific tools in Program or Run mode. If you change the
number of decimal places, entered values will be changed by a factor of ten for each
decimal place added or removed.
