SmartPAC 2 User Manual 1126700
Run Mode 6-31
LOAD NEW TOOL
(RUN – LOAD NEW TOOL)
This item enables you to load a new tool when the press is stopped. (You cannot load a new
tool when the press is running. If you attempt to do so, SmartPAC 2 will display an error
message, indicating that the press must be stopped before a tool can be loaded.) When you
select LOAD NEW TOOL, the Tool Manager screen, shown in Figure 6-25, displays.
Follow these steps to load a new tool:
1. Select LOAD NEW TOOL from the Main Run Menu. The Tool Manager screen displays.
ANCILLARY EQUIPMENT MAY OPERATE WHEN TOOL IS LOADED
Ensure that all personnel stand clear when you load a tool.
Failure to comply with these instructions will result in death or serious injury.
“LOAD NEW TOOL” does not appear on the Main Run Menu if LOAD TOOL # has been set to
PROGRAM MODE ONLY on the Security Access Menu in Initialization mode. See SECURITY
ACCESS, page 4-24.
For help with the Tool Manager screen, which displays which you select the LOAD NEW TOOL
item, press the HELP key when the screen appears.
Figure 6-25. Tool Manager Screen
