SmartPAC 2 User Manual 1126700
Initialization Mode 4-19
Selecting Sensor Enable Mode
You can select one of three modes for enabling die protection sensors:
• MANUAL ENABLE. When this option is selected, sensors are not automatically
re-enabled after the press is restarted following a setup or other procedure in which the
sensors have been temporarily disabled. You must enable or disable sensors manually in
Program and Run modes (see SENSOR ENABLE/DISABLE & STATUS (Optional),
page 5-51 and DISABLE (ENABLE) SENSORS, page 6-5).
• AUTO BY TOOL. When this option is selected, DiProPAC automatically re-enables all
sensors programmed for a specific tool whenever the press is restarted. You specify in
Program mode the number of strokes to allow after the press starts before DiProPAC
re-enables all sensors for the tool (see Setting the “Auto Enable by Tool” Counter Value,
page 5-21).
• AUTO BY SENSOR. When this option is selected, DiProPAC automatically re-enables
each sensor programmed for a specific tool, sensor by sensor. You specify in Program
mode for each sensor the number of strokes to allow after the press is restarted before
DiProPAC re-enables that sensor (see Setting the “Auto Enable by Sensor” Counter Value,
page 5-23).
To select a Sensor Enable mode, do the following:
1. Select SENSOR ENABLE MODE on the Main Initialization Menu. The Die Protection
Mode Selection Menu displays (see Figure 4-14).
2. With the highlight bar on the SENSOR ENABLE MODE item, press ENTER until the
setting you want is displayed.
3. Press RESET to return to the Main Initialization Menu.
Figure 4-14. Die Protection Mode Selection Menu
Pressing ENTER toggles to
AUTO BY TOOL
AUTO BY SENSOR
