SmartPAC 2 User Manual 1126700
Run Mode 6-5
Displaying Multiple Faults
Whenever more than one fault occurs in response to a press condition, the message for the
first fault displays in a window on the Main Run Menu and the label “Display All Errors”
appears to the left of function key F8. To view the multiple errors, press F8. A large red
message window opens, as shown in Figure 6-6, with each fault listed in sequence beneath the
caption “ALL PENDING ERRORS.” To close the window, press RESET.
DISABLE (ENABLE) SENSORS
(RUN – DISABLE [ENABLE] SENSORS)
If this display appears, you need to enter the general password to access the desired item.
Security access is set in Initialization mode (see SECURITY ACCESS, page 4-24).
Figure 6-5. “Enter Your Password” Screen
Figure 6-6. Display All Errors Message Window
DiProPAC has an optional “sensors disabled” output that turns on when the sensors are disabled.
See page 2-31 for details.
ENTER YOUR PASSWORD
USE THE KEYPAD TO ENTER NUMBERS.
USE THE UP/DOWN CURSON KEYS TO
INCREASE/DECREASE. PRESS ENTER
WHEN DONE. PRESS RESET TO CANCEL.
60599
