SmartPAC 2 User Manual 1126700
SmartPAC to SmartPAC 2 Upgrade D-9
Table D-9. SmartPAC 1 to SmartPAC 2 Wiring Changes: ProCamPAC, 16-Channel
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
CHANNEL 1 TB451 260
→
TB451 260
CHANNEL 2 TB451 261
→
TB451 261
CHANNEL 3 TB451 262
→
TB451 262
CHANNEL 4 TB451 263 TB451 263
CHANNEL 5 TB451 264 TB451 264
CHANNEL 6 TB451 265 TB451 265
CHANNEL 7 TB451 266 TB451 266
CHANNEL 8 TB451 267 TB451 267
+ 5 VDC TB451 268 TB451 268
GND TB451 269 TB451 269
RELAY PWR. TB451 270 TB451 270
CHANNEL 9 TB452 271 TB452 271
CHANNEL 10 TB452 272 TB452 272
CHANNEL 11 TB452 273 TB452 273
CHANNEL 12 TB452 274 TB452 274
CHANNEL 13 TB452 275 TB452 275
CHANNEL 14 TB452 276 TB452 276
CHANNEL 15 TB452 277 TB452 277
CHANNEL 16 TB452 278 TB452 278
+ 5 VDC TB452 279 TB452 279
GND TB452 280 TB452 280
RELAY PWR. TB452 281 TB452 281
Table D-10. SmartPAC 1 to SmartPAC 2 Wiring Changes: WPC Port (Integration Only)
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
+RXD6 TB104 219
→
TB105 327
-RXD6 TB104 220
→
TB105 328
+TXD6 TB104 221
→
TB105 329
-TXD6 TB104 222
→
TB105 330
GND TB104 223
→
TB105 326
