4-20 Initialization Mode
Enabling Setup Mode
Setup mode allows you to run the press in Inch without incrementing the good parts and batch
counters or triggering a fault condition in the green sensors. This mode, as its name indicates,
is used during setup. You enable Setup mode by selecting the Inch setting.
To enable Setup mode, do the following:
1. Select SENSOR ENABLE MODE on the Main Initialization Menu. The Die Protection
Mode Selection Menu displays.
2. Move the highlight bar to the SETUP MODE item.
3. Press ENTER to toggle the setting from DISABLED to INCH.
4. Press RESET to return to the Main Initialization Menu.
TOOL INFORMATION
(INITIALIZATION – TOOL INFORMATION)
The TOOL INFORMATION item on the Main Initialization Menu allows you to set up a
name, unit of measurement, and number of decimal places for up to six items you wish to
document for each tool. You enter specific values and up to thirty characters of special
information for each tool in Program and Run modes (see TOOL INFORMATION, page 5-49
and TOOL INFORMATION, page 6-28).
To set up items you wish to document for each tool, do the following:
To enable Setup mode, your inch-selector switch must be wired to the Setup mode input, terminal
#252 on TB107 (see Wiring Setup Mode Circuit, page 2-31).
Tool Information screens only maintain information about the tool. They do not control any aspect
of press operation.
This feature is not available if you have the optional PLC interface installed.
