SmartPAC 2 User Manual 1126700
Program Mode 5-11
Each batch counter is assigned to a specific ProCamPAC channel: Batch 1 to Channel 6,
Batch 2 to Channel 7, and Batch 3 to Channel 8. If you set a Batch counter to either
TOGGLE or PULSE, the ProCamPAC channel controlled by that counter is displayed on
the Counters screen (see Figure 5-11).
The crankshaft angle at which Strokes, Good Parts, Total Hits, and Batch counters is
incremented can also be programmed.
Setting Preset Values
Counter presets specify the count at which SmartPAC 2 initiates one of three programmed
actions (i.e., Top-stop, Toggle, or Pulse). To enter counter presets, do the following:
1. On the Tool Program Menu, select COUNTERS to display the Counters screen.
2. Select the setting displayed in the PRESET VALUE column of the counter you want to
program. The Numeric Entry window (see Figure 5-3, page 5-3) displays.
3. Key in a preset value, following the directions in the window, and press ENTER. The
value you entered displays in the PRESET VALUE field for the counter you selected in
step 2.
4. Repeat steps 2 and 3 for each counter preset you want to program.
Changing Count Values
Under some circumstances, you may need to adjust the count upward or downward, or you
may want to start the count at some value other than zero. To change count settings, do the
following:
If this display appears, you need to enter the general password to program preset values.
Security access is set in Initialization mode (see SECURITY ACCESS, page 4-24).
Figure 5-12. “Enter Your Password” Screen
You can disable a counter by setting its preset value to zero.
ENTER YOUR PASSWORD
USE THE KEYPAD TO ENTER NUMBERS.
USE THE UP/DOWN CURSON KEYS TO
INCREASE/DECREASE. PRESS ENTER
WHEN DONE. PRESS RESET TO CANCEL.
60599
