4-2 Initialization Mode
The first display you see in Initialization mode is the Main Initialization Menu (see
Figure 4-1). From this menu, you can access all the Initialization mode displays.
The following sections show you how to use the selections available on the Main Initialization
Menu to set initialization parameters for SmartPAC 2 with ProCamPAC and DiProPAC.
RESOLVER ZERO
(INITIALIZATION – RESOLVER ZERO)
This item enables you to zero the resolver. You must zero the resolver when you first install
SmartPAC 2 and whenever you replace the resolver. For instructions on how to zero the
resolver, refer to Zeroing the Resolver, page 2-35.
Table 4-1. Instructions for Entering and Exiting Initialization Mode
To Enter Initialization Mode To Exit Initialization Mode
1. Turn Program/Run key to PROG.*
2. Press the “1” and “CLEAR” keys
simultaneously and hold down a few
seconds until the Main Initialization Menu
appears.
To switch to Program mode:
Press RESET.
____________________________________
To switch to Run mode:
Turn the Program/Run key to RUN.*
* If you turn the key and nothing happens, press RESET repeatedly until SmartPAC 2 changes modes. Make sure SmartPAC
2 is in the Main (or top) menu for the mode it is in before you turn the Program/Run key. If SmartPAC 2 is not in a top-level
menu, press RESET repeatedly until the Main menu appears.
SET THE INTERNAL CLOCK IN SMARTPAC 2
When you initialize your SmartPAC 2, be sure to set the clock to the correct date and to your local
time according to the instructions in
SET CLOCK, page 4-41.
To Next Page
