SmartPAC 2 User Manual 1126700
Initialization Mode 4-17
3. Select the type of cam timing you want to program for this channel, referring to CAM
SWITCH (Optional), page 5-37 for instructions.
4. When you have finished programming the global cam, press RESET.
CUSTOM SENSOR NAMES (Optional)
(INITIALIZATION – CUSTOM SENSOR NAMES)
This item, which appears on the Main Initialization Menu only when DiProPAC is installed,
allows you to create “custom” names for up to 32 die protection sensors. The custom names
you create in Initialization provide the options available to you in Program mode when you
select names for your sensors. You create custom names on the Custom Sensor Names
screen, which is shown in Figure 4-13, page 4-18.
Figure 4-12. Global Cam Timing Type Screen
You can use a separate computer keyboard to enter custom sensor names. See page 4-45.
Custom Name entries 17-32 display sequentially, one at a time as you move the highlight bar
down past the CUSTOM 16 item.
Custom names do not have to be entered in the sequence that you use to name sensors. Sensor
1 can be assigned Custom Name 32, Sensor 2 Custom Name 15, Sensor 3 Custom Name 5, etc.
See page 5-22 for instructions in assigning custom names to sensors.
