6. RADAR
6-19
* Cannot be adjusted when the Target Analyzer (radar sensor DRS4D-NXT) is active.
The no.1 screen is independent of the no.2 screen when the no.2 screen is in standby.
However, when the no.2 screen goes to transmit state, so does the no.1 screen.
6.25 Target Analyzer
The target analyzer paints radar echoes in the colors shown in the table below, to help
you distinguish approaching targets from all other radar echoes. Requires GPS posi-
tion data. Radar Adjust (Gain, Sea, Rain) and Auto Sea Mod cannot be adjusted when
the Target Analyzer is active.
Target analyzer is available with the DRS4D-NXT radar sensor.
Target type and color painted by the target analyzer
Orientation mode (head-up or north-up) Independent Independent
Rain clutter Independent Interlocked
Range scale control Independent Independent
Range max. range scale 36 NM 12 NM
Range rings (show, hide) Independent Independent
RezBoost - Independent
Sea clutter Independent Interlocked
Clear Trail Independent Independent
Target type Color
Approaching target Red
Rain clutter Blue ([Target Analyzer Mode] ([Radar] menu) set to [Rain].)
Targets other than mentioned above Green
Radar function
Availability in dual range mode
Magnetron radar Solid state radar
Two-way split
Three-way split
No.1
screen
No.2
screen
No.1
screen
No.2
screen
No.1
screen
No.2
screen
No.2
screen
No.1
screen
