11. INSTRUMENT DISPLAY
11-5
Auto mode
11.3.7 Highway display
The highway display provides a graphic presentation of your vessel’s progress toward
a waypoint. The example belows the highway display when following a route.
Mode
(Auto)
Blue arrow: Set course
Gray arrow: Heading
Set
course
Heading
(digital)
Coarse adj. buttons
In AUTO mode, XTE,
DTW, TTG and ETA
indications show “---”.
Goto waypoint*
* “Goto” shown when navigating to a single point.
Speed over
the ground
Course over
the ground
Cross track
error
Distance to waypoint
TTG to waypoint
ETA to
waypoint
Direction to steer
(Red): Steer left
(Green): Steer right
