1. SYSTEM INTRODUCTION
1-17
1.10 RotoKey Menus
The main function of the RotoKey
TM
is to display the
RotoKey menu, which is a set of menu items that
change with the operating mode. For TZT9/TZT14, push
the RotoKey
TM
to display the RotoKey menu then ro-
tate the RotoKey
TM
to select a menu item. You can also
select a menu item by dragging with a finger. When you
search through the menu item, the now-selected menu
item is the longest and surrounded in yellow. For
TZTBB, tap the screen to display the RotoKey menu. If
the menu you are looking for is not shown, select
[More...] (then drag the menu items) to select a menu
item. Push the RotoKey
TM
or tap the menu item to do
the function shown on the selected menu item. For de-
tails, see section 14.1.
The indication at the end of a menu item indicates menu item category:
• The "" mark indicates a multi-function menu item. Push the RotoKey
TM
(or tap the
menu item desired) to go to the next level.
• The "" mark indicates ON status (selected) of the item shown on the menu item.
The "" mark disappears with OFF status (deselected). Push the RotoKey
TM
(or
tap the menu item desired) to switch ON or OFF.
This manual states these operation procedures as follows:
ON status with the "" mark: Select [menu item name].
OFF status: Deselect [menu item name].
• There is no mark on a menu item that does the function labeled on the control, for
example, [Hdg Ln Off] in the radar display. Push the RotoKey
TM
(or tap the menu
item desired) to process the item.
RotoKey
TM
(for TZT9/
TZT14)
Selected
menu item
(longest and
indicated with
a yellow
highlight)
Additional functions
Function ON
Function OFF
Hdg Ln Off
Echo Trail
Rings
◄
Radar Filters
◄
Orientation
Radar Filters
Rings
Orientation
Hdg Ln Off
Echo Trail
For TZTBB For TZT9/TZT14
◄
◄
Tx Radar
Radar Adjust
Rings
More...
◄
Select [More...]
to display
hidden menus.
To Next Page
