7. FISH FINDER
7-16
3. Select a mark. In the example below, a shrimp mark is put on the fish symbol.
How to go to a point or a position
1. Select a fish symbol (only in ACCU-FISH
TM
mode), a point or a position to display
the pop-up menu.
2. Select [Go To]. The selected symbol*, point* or position is highlighted on the chart
plotter display. For details, see section 4.11.
*: When [Accu Fish] or [Points] is turned on in the [Overlay] RotoKey menu.
7.12 Fish Finder Menu Operation
This section describes the fish finder functions not described in previous sections. To
open the following menus, select [Menu] on the menu icon bar then select [Sounder].
[Day Background Color]: Select the background color for use during daylight hours.
The options are [White], [Light Blue], [Black] and [Dark Blue].
[Night Background Color]: Select the background color for use at nighttime. The op-
tions are [Black] and [Dark Blue].
[Echo Color Levels]: Select the number of colors shown on the screen. The selections
are [8 Colors], [16 Colors] and [64 Colors].
[Zoom Reference Lines]: Show or hide the zoom marker, which appears in the bottom
lock and bottom zoom modes.
294
XXXXX
Fish Finder Source
Day Background Color
Night Background Color
Echo Color Levels
A-Scope Peak Hold
Zoom Reference Lines
High Resolution
Picture Advance
Range Shift
0.0 ft
Bottom Range Shift Area
Zoom Range Span
Bottom Lock Range Span
64 Colors
1/1
30.0 ft
30.0 ft
75
ACCU-Fish Info
ACCU-Fish Symbols
ACCU-Fish Size Correction
Heaving Correction
Interference Rejection
Clutter
TVG HF
TVG LF
Transmit Rate Mode
Transmit Rate Manual Value
Sounder Transmit
Depth
Solid
0
Auto
0
5
5
20
Manual
To Next Page
