11. INSTRUMENT DISPLAY
11-2
11.3 Instrument Displays
11.3.1 Steering display
The steering display provides the analog and digital indications shown below.
11.3.2 Engine display
The engine must output engine data in NMEA 2000 format to show the engine data.
The data for a maximum of four engines can be displayed.
HDG: Heading
COG: Course over ground
SOG: Speed over ground
CTS: Course to steer
(Steer to direction)
DTW: Distance to waypoint
TTG: Time to go
XTE: Cross-track error
Steer to direction (P: Port, S: Starboard)
Warning: Lights in red
for engine trouble
other than engine
overheating.
RPM: Revolutions per minute
Engine temperature
Oil pressure
Temperature: Lights in
green for high engine
temperature.
Analog and digital tachometer
104
°
F
1,000.0 rpm
