14-1
14. HOW TO ADJUST SETTINGS
After you understand the basic operation procedures of your equipment, you can set
the equipment according to your needs.
• Set the equipment according to your system configuration.
• Change how the equipment operates and displays information.
All the adjustments are done from the menu. To restore the default settings for the se-
lected menu, select [Reset Default Settings] that is provided on each menu.
Some of the items which you can adjust are as follows:
14.1 RotoKey Mode
The user can select how many menu items to make available with the RotoKey
TM
(touch control for TZTBB) in the chart plotter, weather, radar, sounder, instrument and
camera modes. The two quantities are [Base] and [Full].
The table below shows the menu items available for use in the chart plotter, weather,
radar, sounder, instrument and camera modes.
Note: The menu items shown on the screen depend on your system configuration,
equipment settings or functions in current use.
Menu items available in the chart plotter mode
• RotoKey mode • Data boxes • Units of measurement
• System settings • Charts
Control label
Function Base Full
Level 1 Level 2
Route Stop Nav. Stop following a route. Yes Yes
Restart Nav. Restart course. Yes Yes
Skip Wpt Skip a go to point on a route. Yes Yes
Orientation North Up Set orientation mode to north up. Yes Yes
Head Up Set orientation mode to head up. Yes Yes
Track Rec. - Record track of your ship. Yes Yes
Event - Put an event mark. Yes Yes
Lat/Lon - Create a point using the software
keyboard.
Yes Yes
3D - Switch the display view from 2D to
3D.
Yes Yes
Chart Raster Show raster chart. Yes Yes
S-57 Show S-57 chart. Yes Yes
C-MAP Show C-MAP chart. Yes Yes
Navionics Show Navionics chart. Yes Yes
Fishing Show fishing chart. Yes Yes
Auto Switch the chart type automatical-
ly.
Yes Yes
