1. SYSTEM INTRODUCTION
This chapter provides the information necessary to get you started using your system.
Some of the topics are how to turn on the equipment and an introduction to the main
screens.
Standards used in this manual
• TZT9/TZT14: There are three keys on the control panel: Home, RotoKey
TM
and Pow-
er.
TZTBB: There is a power key on the switch box (PSD-002). The home key is dis-
played at the top right-hand corner of the screen as an icon ( ) instead of a key. The
TZTBB does not have a RotoKey
TM
.
The Home and RotoKey
TM
are shown in bold face. The power key is indicated as
key. Other items that appear on the screen with touch controls or the
RotoKey
TM
, are shown in brackets in normal typeface. For example, [Head Up].
• The menu system has main menus and related sub menus.
How to operate the main menu
1. TZT9/TZT14: Press the Home key to display the menu icon bar (see
section 1.13).
TZTBB: Tap the Home icon at the top right-hand corner of the screen.
2. Select (tap) the [Menu] icon to open the main menu.
This manual states steps 1 and 2 as “Select [Menu] on the menu icon bar to open
the main menu.”
3. Drag the main menus to display a menu desired. The selected menu is indicated
with a yellow highlight. The sub menus for the selected menu appear (see
section 1.13).
When you are asked to select a menu item from the main menu, the name of the main
menu and sub menu are given, separated by a hyphen. For example, "Select the
[Routes] - [Default Route Color] menu".
• This equipment has a RotoKey menu that gives you access to full control of the
NavNet TZtouch system.
How to operate the RotoKey menu
1. TZT9/TZT14: Push the RotoKey
TM
to open the RotoKey menu.
TZTBB: Tap the screen.
2. Select a menu item as follows:
• TZT9/TZT14: Rotate the RotoKey
TM
to select a menu desired then push the
RotoKey
TM
to do the function.
• TZT9/TZT14/TZTBB: Drag the RotoKey menu to display a menu desired then
select (tap) it to do the function marked on the menu item.
This manual states this operating procedure as "Select [menu name] from the
RotoKey menu.”
• The colors mentioned for track, route, point, etc. are the default colors.
• This manual states the operation for the home and Rotokey functions based on TZT9/
TZT14.
• Most of the screenshots in this manual are for TZT9/TZT14.
