6 - 39
6 Performing Measurement and Adjustment
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
6-6 Updating the Reference Position Data for a Unit in the Measurement Flow [Update Stan-
dard Position Tool]
6
6-6-1 Monitoring Measurement Value Trends [Trend monitor]
 To Cancel Updating
Click the [Cancel] button. You can return the reference positions to the values that were in effect
before you opened this tool.
Additional Information
Most of the measurement items automatically update their reference positions when the model
or measurement area is changed.If you need to change the reference position after it is
updated, place the workpiece in the desired position, and then update the reference positions
for all measurement units that you wish to change in the measurement flow.
By monitoring the trends in measurement values, the occurrence of defects can be prevented in
advance and this information can also be helpful in NG error occurrence cause analysis. Use the [Trend
Monitor] processing item to monitor the measurement values.
Refer to Trend Monitor in the Vision System FH/FHV/FZ5 Series Processing Item Function Reference
Manual (Cat. No. Z341).
6-6-1 Monitoring Measurement Value Trends [Trend monitor]
Judgment lower limit
Judgment upper limit
Warning (Upper limit)
Warning (Lower limit)
NG
NG
Warning occurs.
Warning occurs.
